This course aims to fulfill the following points: - Lighting Shop drawing plans 1- How to prepare lighting shop drawing plans. Change symbols in lighting plan design. Put Dimensions. Conduit types. Embedded conduits & Exposed conduits. Wire mark. Details .2- Apply on hospital project. 3- Give you a feedback with the possible consultant comments on lighting shop drawing plans. Power shop drawing plans 4- How to prepare power shop drawing plans. Change symbols in power plan design. Put Dimensions. Conduit types. Embedded conduits & Exposed conduits. Wire mark. Details .5- Apply on hospital project. 6- Give you a feedback with the possible consultant comments on power shop drawing plans. Cable routing shop drawing plans 7- How to prepare cable routing shop drawing plans. How to prepare filling ratio sheet. How to prepare cable tray sections on AutoCAD. 8- Apply on hospital project. 9- Give you a feedback with the possible consultant comments on cable routing shop drawing plans. Panel schedule 10- How to update panel schedule consultant sheets. Consultant comments 11- How to cover these comments to get an approved drawings. 12- Some tools that help in covering the consultant possible comments: - How to make short circuit calculations. How to make Voltage drop calculations. Lighting calculations using ( DIALUX EVO ) .
